Under a special type of SBIR/STTR contract – known as a Direct-to-Phase II award, offered by the Air Force Research Laboratory Center for Rapid Innovation – Echo Ridge is working with the AFRL Sensors Directorate to solve this pressing issue.
Adversaries use GPS jammers to disrupt allied operations as well as to protect themselves from attack by aircraft launched precision weapons. These jammers deny access to the GPS signal for our ground forces in the region, making it difficult to navigate.
Echo Ridge developed and applied its technology to build a hand-held device that can provide navigation information to ground forces, according to Mark Smearcheck, an electronics engineer with the AFRL Sensors Directorate. The company worked to provide a complementary, backup source of positioning, navigation, and timing by creating an algorithm to aggregate signals of opportunity from various radio frequency sources. The algorithm is used to determine a position based on the time difference of arrival of those signals, which do not operate on the same frequency as GPS.
By receiving and processing various radio frequency sources not designed for navigation purposes, the new system can pinpoint a user’s location without relying on GPS. The device connects to a smart phone running the Android Tactical Assault Kit, a device typically carried by Air Force ground operators, to display the navigation solution on a map.
With the process developed by Echo Ridge, the errors do not accumulate over time, as they might with a traditional dead-reckoning approach, so a valid position can be produced indefinitely. Additionally, multiple signal sources are used simultaneously, which provides redundancy and increased immunity to adversarial attack.
“We’re measuring signals that have known or discovered geographical locations,” said John Carlson, chief technical officer at Echo Ridge. “Because we’re able to precisely measure those signals, we can accurately estimate position without error growth over time or distance traveled.”
Funding provided by the Air Force SBIR/STTR Program allowed Echo Ridge to turn a laboratory concept into a prototype device in a small, low-power package.
Echo Ridge and the AFRL Sensors Directorate recently completed a field test and demonstration at Fort Bragg, North Carolina. The company is working to improve usability and address ruggedness issues that would position the device for wider use in the field. While still in the development phase for the Air Force, this technology has sparked interest from other potential federal customers.
“The Air Force SBIR/STTR Program really helps take some of the risk out of developing technology like this,” Carlson said. “The funding was absolutely critical to our efforts.”
